Innolux 6.5Inch Industrial LCD Panel with 640x480 Resolution 200 cd/m² Brightness and 50pin Interface for Video Door Phone and Digital Photo Frame

Brand Name : innolux

Model Number : AT056TN52

Certification : Rohs,CE,FCC

Place of Origin : China

MOQ : 10pcs

Price : Negotiation

Payment Terms : T/T,W,Western Union,MoneyGram

Supply Ability : 3000pcs per week

Delivery Time : 4-5 working day

Packaging Details : Industrial packing

Quality : Brand new Original

Package : Original industrial packing

resolution : 640*480pixels

style : WLED 60P

brightness : 200 CCD M2

color : 262K

contrast ratio : 500 :1

working life : 20K Hours

Contact Now

Innolux 6.5-Inch Industrial LCD Panel
High-quality 640*480 resolution TFT-LCD display with 200 cd/m² brightness, designed for industrial applications including video door phones and digital photo frames.
Product Overview
The Chimei Innolux AT056TN52 V.3 is a 5.6-inch diagonal a-Si TFT-LCD display panel with integrated WLED backlight system. This industrial-grade panel features wide operating temperature ranges and is suitable for various embedded applications.
Technical Specifications
BrandChimei Innolux
Model NumberAT056TN52 V.3
Diagonal Size5.6 inches
Panel Typea-Si TFT-LCD, LCM
Resolution640(RGB)*480 (VGA), 143 PPI
Active Area112.896 * 84.672 mm
Brightness200 cd/m² (Typical)
Contrast Ratio500:1 (Typical)
Viewing Angle70/70/50/70 (CR≥10)
Response Time10/15 ms (Tr/Td)
Display Colors16.7 million
Backlight3S5P WLED, 20,000 hours
Signal InterfaceParallel RGB (1 ch, 8-bit), 50-pin FPC
Input Voltage3.3/5.0/15/-10V (VCC/AVDD/VGH/VGL)
Operating Temperature-20°C to 70°C
Storage Temperature-30°C to 80°C
Panel Weight127.5g (Typical)
Application Examples
Innolux 6.5Inch Industrial LCD Panel with 640x480 Resolution 200 cd/m² Brightness and 50pin Interface for Video Door Phone and Digital Photo Frame Innolux 6.5Inch Industrial LCD Panel with 640x480 Resolution 200 cd/m² Brightness and 50pin Interface for Video Door Phone and Digital Photo Frame Innolux 6.5Inch Industrial LCD Panel with 640x480 Resolution 200 cd/m² Brightness and 50pin Interface for Video Door Phone and Digital Photo Frame Innolux 6.5Inch Industrial LCD Panel with 640x480 Resolution 200 cd/m² Brightness and 50pin Interface for Video Door Phone and Digital Photo Frame
Additional Information
This model entered mass production in Q2 2009 with last shipment in Q4 2022 and is now discontinued. For current production status and latest specifications, please contact Chimei Innolux or their authorized distributors.
Innolux 6.5Inch Industrial LCD Panel with 640x480 Resolution 200 cd/m² Brightness and 50pin Interface for Video Door Phone and Digital Photo Frame
Product status information is provided for reference only and should not be used as the sole basis for decision-making. Always verify current production status with the manufacturer.
